Adjustable swing gate, 3.4m wide, MEIJE, 160cm high, grey aluminum
- Allows you to adapt the gate to your space
- Suitable for spaces from 336.7 cm to 351.7 cm
- 2 XL hinges for width adjustment
- 2 privacy panels to conceal the gap
Our categories:
Suggested products:
KIT-000760
8899 kr
Secure payment
Delivery within 5 days
Free shipping
3.4m MEIJE swing gate, 160cm high, grey aluminum
8899 kr
Save money! Discover the packs bundled with this product
-5%
between 0 kr and 11174.99 kr*
-7%
between 11175 kr and 22349.99 kr*
-10%
greater than 22350 kr*
*HT orders
Looking for a gate with a timeless style? Discover the MEIJE range and its distinctive arched design.
The MEIJE arched gate combines classic elegance with robustness. The rounded upper bars add a touch of softness while allowing light to filter through, while the solid lower section ensures privacy and security. This aluminum swing gate is ideal for those seeking a balance between tradition and modernity for their exterior.
Swing Gate: Elegance and Practicality for Your Exterior
The double swing gate is an excellent choice for combining aesthetics and functionality. Thanks to its two leaves, it opens wide to provide comfortable access to your property while optimizing available space. Robust and durable, this type of gate is also distinguished by its ease of installation and low maintenance. Adding a swing gate motor will make it even more convenient, automating its opening and closing on a daily basis.
This swing gate has a wind resistance of 55 km/h.
Material: Aluminum
Color: Anthracite Gray - RAL 7016
Dimensions: Height 160.6 cm - Width 334.7 cm
Required width between posts: 339.7 cm
Minimum post height: 175 cm
- 18 wide powder-coated slats (15.5 cm wide)
- 16 narrow powder-coated slats (7.75 cm wide)
- 2 upper hinges mounted on ball bearings
- 2 lower hinges
- 1 receiving stop
- 1 automatic center stop
- 1 cylinder lock
- 1 handle (black)
- 5 keys
- Finishing caps
- Screws
About the Material
Aluminum is appealing due to its lightness and ease of handling, making it easy to install on all types of terrain. A modern material, it offers a wide range of designs and colors to harmonize with your exterior. Resistant to impacts and weather variations, it remains intact over time. By choosing aluminum, you benefit from a versatile, customizable, and durable solution to enhance your outdoor space.
The minimum height of the posts for this swing gate is 175 cm.
How to maintain your aluminum structure?
Aluminum requires little maintenance, but regular cleaning prolongs its lifespan. Once or twice a year, simply use warm soapy water with a soft cloth, then rinse and dry thoroughly. Avoid abrasive products and high-pressure cleaning, which could damage the lacquer.
Need help choosing your swing gate?
Contact our customer service department via our online form.
Clear instructions
Quick and easy assembly
Find all the necessary information about this product in the Technical specifications
Download the instructionsMain material
Aluminum
RAL
7016
Opening direction
To the house
Operating clearance
30 mm
Thickness of the blades
1 mm
Stud thickness
1.5 mm
Sleeper Section
30*77 mm
Locking system
Barrel lock
Handle material
Aluminum
Handle colour
Black
Type of lock
5 keys
Rod assembly
Self-drilling screws
Number of upper hinges
2
Assembly time
7 h
Compatible engines
Yes
Height
158 cm
Width between pillars
339.7 cm
Sleeper thickness
1.1 mm
Number of lower hinges
2
Recommended number of persons for assembly
2
Eligibility Extended warranty 5 years
No
Wind resistance
55 km/h
Assembly instructions
Yes
Available in sliding
No
Blade section
130*15 mm
Colour
Charcoal grey
Finishing
Power coating
Minimum pillar height
160 cm
Compatible motorization type
With articulated arm and jacks
Pivoting system
Ball bearing
Stud/rail assembly
Self-drilling screws
Frame material
Aluminium
Supplied accessories
Yes
Amounts Section
47*78 mm
Compatible pillar spacing
331.7 - 336.7 cm
Width
334.7 cm
Top cover cap
Yes
Central stop
Yes
End stop
2
Warranty
2 an(s)
Eligibility Extension of warranty 10 years
No
Opening system
Swing gate
